Description

Condition: New

12" woofer, capable of moving plenty of air with power and precision
Cone is made from pure aluminium for maximum stiffness
170W RMS Class D amplifier with a highly linear response
SUB E-12 F features controls for volume adjustment, phase, and upper cut-off frequency

The heart of this subwoofer is the 170W RMS Class D amplifier with a highly linear response. Embracing a classic DALI trademark, it simply acts as a total low frequency extension of your AV system. The result is a powerful, well-balanced bass reproduction and flawless integration with your speakers. In addition, the integrated limiter helps protecting your subwoofer against overloading.

The back plate of SUB E-12F features controls for volume adjustment, phase, and upper cut-off frequency, while the power on/off function works automatically via signal detection. And with the options for LFE or LINE inputs, this subwoofer easily accompanies any AV set up.

The DALI SUB-12F is recommended as compliment to the new OBERON and SPECTOR series and is compatible with all DALI loudspeakers as the perfect completion of a DALI surround set up.

Bauart Subwoofer
Frequenzbereich (+/- 3 dB) 28 - 190 Hz
Maximaler Schalldruckpegel 112 dB
Übergangsfrequenzen 40 - 120 Hz
Tieftöner 1 x 30cm langhub Aluminium-Polymere-Membran
Gehäusetyp Bass Reflex
Bassreflex-Abstimmfrequenz 36 Hz
Maximale Verstärkerleistung [RMS Watt] 220
Verstärker Dauerleistung [RMS Watt] 170
Eingangsimpedanz 25 kOhm
Eingang Mono line level (LFE)
Stereo line level (low pass filtered)
RCA
Empfohlener Wandabstand [cm] 5 <
Funktionen Crossover Frequency
Phase Switch
Maximaler Stromverbrauch [Watt] 250
Maximale Abmessungen mit Basis und Abdeckung (HxBxT) 370 x 340 x 380 mm
