Description

H×W×D - 1,000mm×232mm×86mm

Weight - 4.1kg

PC-80 Hardware Specifications

Number of Audio Record/Playback Channels
Record: 1 pair of stereo
Playback: 1 pair of stereo

Full duplex (except for 96 kHz setting)

Signal ProcessingAD/DA Conversion: 24 bits
PC Interface: 24 bitsMaster Volume Knob

Number of Audio Record/Playback Channels

Sampling Rate
44.1/48/96 kHzNominal Input Level-45--0 dBu
Input Impedance
LINE: 15 k ohms
GUITAR, MIC: 680 k ohmsMaximam Output Level

Audio Output Jacks (L,R): +5dBu
Audio Output Jack (SUBWOOFER): -2dBuOutput Impedance1 k ohmsResidual Noise Level-80 dBu or less (INPUT MONITOR: OFF, MASTER VOLUME: MAX, IHF-A, typ.)
Connectors
Audio Input Jacks (L/MONO, R): 1/4 inch phone type
Audio Output Jacks (L, R, SUBWOOFER): RCA phono type
Headphones Jacks: Stereo 1/4 inch phones type x 2
Hold Pedal Jack: 1/4 inch phone type
Expression Pedal Jack: 1/4 inch TRS phone type
MIDI OUT Connector
USB Connector
DC IN ConnectorKeyboard61 Keys (with velocity)ContorollersMaster Volume Knob

MIDI Channel Button
Program Change Button
Software Synthesizer Button
Split Buttons (LOWER/UPPER)
Direct Monitor Button
Octave Shift Buttons (+/-)

Pitch Bend/Modulation Lever
Value Encoder
Audio Input Level KnobDisplay7 segments, 3 characters (LED)

Rear PanelPower Switch (USB/OFF/DC)
Audio Input Level KnobPower SupplyDC 9 V (AC Adaptor) or USB Bus PowerCurrent Draw2000 mA (AC Adaptor)
500 mA (USB Bus Power)AccessoriesAC Adaptor (PSB-1U)
CD-ROM (PC-80 Software, SONAR LE)
USB Cable
Owner's Manual
Roland Software License AgreementOptionsPedal Switch: DP-2
Expression Pedal: EV-5
