Description

Type

2 x XLR jacks, balanced

Mic E.I.N. (20 Hz to 20 kHz)

-129 dBu, A-weighted

Distortion (THD+N)

< 0.004%, A-weighted

Max. input level

+20 dBu

Impedance

10 kΩ balanced, 5 kΩ unbalanced

Type

2 x XLR / 1/4" TRS combo jacks, balanced

Mic E.I.N. (20 Hz to 20 kHz)

-117 dBu, A-weighted

Distortion (THD+N)

< 0.01%, A-weighted

Max. input level

XLR: +6 dBu TRS: +26 dBu

Impedance

XLR: 2 kΩ balanced, 1 kΩ unbalanced TRS: 20 kΩ balanced, 10 kΩ unbalanced

Gain range

-20 dB to +60 dB

Phantom power

+48 V, switchable (inputs 1 / 2 only)

Type

2 x 1/4" TRS jacks, balanced (channels 5L / 7L)

Impedance

20 kΩ balanced, 10 kΩ unbalanced

Distortion (THD+N)

0.005%, A-weighted, 0 dB gain, 0 dBu out

Max. input level

+22 dBu

Type

2 x 1/4" TRS jacks, balanced (channels 6R / 8R)

Impedance

2 MΩ balanced, 1 MΩ unbalanced

Max. input level

+19 dBu

Low

±15 dB @ 20 Hz, shelving

Low mid

±15 dB @ 300 Hz

High mid

±15 dB @ 1.5 kHz

High

±15 dB @ 20 kHz, shelving

Type

2 x 1/4" TRS jacks, balanced

Impedance

75 Ω, balanced

Max. output level

+14 dBu

Impedance

150 Ω, balanced

Type

1 x 1/4" TRS jack, stereo

Max. output level

+18 dBm / 40 Ω

Type

1 x 1/4" TRS jack (tip / ring normally open)

Function configurable

FX mute / Tap tempo or Snapshot load next / previous

Frequency range

10 Hz to 22 kHz (+0/-1 dB)

Dynamic range, analog in to analog out

Typ. 108 dB

I/O latency

0.6 ms

Signal processing

32-bit VFP (Vector Floating Point)

A/D - D/A conversion

24-bit / 48 kHz

Dynamic range

114 dB

Number of input processing channels

10 input channels, 4 fx return channels

Interface type

USB 2.0

Connector

Type B

Bit depth

24-bit / 48 kHz

Channels

10 out / 2 in

Frequency range

2402 MHz ~ 2480 MHz

Channel number

79

Version

Bluetooth spec 4.0 compliant

Compatibility

Supports A2DP 1.2 profile

Max. communication range

12 m (without interference)

Max. output power

8 dBm

Connector

Micro-USB

Power supply

5 VDC 2A

Power consumption

Max. 10 W (typ. 5 W)

Dimensions (H x W x D)

48 x 229 x 172 mm (1.9 x 9.0 x 6.8")

Weight

1.4 kg (3.1 lbs)
