Description

48 x 10/ 100/ 1000 (PoE+)
4 x Gigabit SFP

Product Description
HP 2530 switch series consists of four fully managed layer 2 edge switches, delivering cost-effective, reliable, and secure connectivity for business networks. Designed for entry-level to midsize enterprise networks, the Gigabit Ethernet switch delivers full layer 2 capabilities with enhanced access security, traffic prioritization, and IPv6 host support. The 2530 switch has 48 10/100/1000 ports and four small form-factor pluggable (SFP) slots for fiber connectivity. For customers implementing Power over Ethernet for voice, video, or wireless deployments, the HP 2530-48G-PoE+ Switches is IEEE 802.3af and IEEE 802.3at compliant with up to 30 W per port. The HP 2530 switch series is easy to use, deploy, and manage via SNMP, CLI, and web GUI. The series offers flexible wall, table, and rack mounting; quiet operation; and improved power savings, with features such as IEEE 802.3 az (Energy Efficient Ethernet).
Technical Specs
General
Interfaces Gigabit Ethernet
Jumbo Frame Support 9220 bytes
Enclosure Type Desktop, rack-mountable, wall-mountable 1U
Performance Throughput: 77.3 Mpps ¦ Switching capacity: 104 Gbps
Processor 1 x ARM: 800 MHz
RAM 256 MB DDR3 SDRAM
Device Type Switch - 48 ports - Managed
Subtype Gigabit Ethernet
Ports 48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE) PoE+
MAC Address Table Size 16000 entries
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI
Encryption Algorithm SSL
Authentication Method RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features Flow control, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Multicast Suppression, STP Root Guard, LLDP support, dual firmware images, Class of Service (CoS), Generic Attribute Registration Protocol (GARP)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Flash Memory 128 MB
Power
Voltage Required AC 120/230 V (50/60 Hz)
Power Device Internal power supply
Expansion / Connectivity
Interfaces 48 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - PoE+ ¦ 4 x SFP+ ¦ 1 x management - RJ-45
Miscellaneous
Compliant Standards FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1
Dimensions & Weight
Width 44.3 cm
Depth 32.26 cm
Height 4.45 cm
Weight 4.72 kg
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 45 °C
Humidity Range Operating 15 - 95% (non-condensing)
Min Storage Temperature -40 °C
Max Storage Temperature 70 °C
