1x USB-C port for connection to a laptop with USB-C or ThunderboltTM 3/4 (100 cm USB-C cable included)
Power Delivery: 100 W
Video Ports: 2x DisplayPort, 1x HDMI
Resolution:
Host device with DisplayPort 1.2 support:
1 monitor – 1x HDMI or DP→ up to 4K/30Hz
1 monitor – 1x HDMI or DP → up to 1080p/120Hz
2 monitors – 1x DP + 1x HDMI → up to 2x 1080p/60Hz*
2 monitors – 2x DP → up to 2x 1080p/60Hz*
3 monitors – 1x HDMI + 1x DP + 1x DP → up to 1x 1080p/60Hz + up to 2x 720p/60Hz*
Host device with DisplayPort 1.4 support:
1 monitor – 1x HDMI → up to 4K/60Hz
1 monitor – 1x DP → up to 4K/60Hz
2 monitors – 1x DP + 1x HDMI → up to 2x 1440p/60Hz*
2 monitors – 1x DP + 1x HDMI → up to 2x 4K/30Hz*
2 monitors – 2x DP → up to 2x 4K/30Hz*
3 monitors – 1x HDMI + 1x DP + 1x DP → up to 3x 1080p/60Hz*
Host device with DisplayPort 1.4 with DSC support:
1 monitor – 1x HDMI → up to 4K/60Hz
1 monitor – 1x DP → up to 5K/60Hz
1 monitor – 1x HDMI → up to 1440p/144Hz or 1080p/240Hz
1 monitor – 1x DP → up to 4K/144Hz or 1440p/240Hz or 1080p/360Hz
2 monitors – 1x DP + 1x HDMI → up to 2x 4K/60Hz*
2 monitors – 1x DP + 1x HDMI → up to 2x 1440p/144Hz*
3 monitors – 1x HDMI + 1x DP + 1x DP → up to 3x 4K/30Hz*
3x USB 3.0Gen 1 (5Gbps)
1x USB 3.0 Gen 1 (5Gbps) with fast charging support (BC 1.2)
1x Ethernet GLAN RJ-45 port (Realtek RTL8153)
1x SD slot
1x microSD slot
1x 3.5mm Audio combo jack
1x power input (20V/6.5A)
MAC Address cloning: Yes (using i-tec Docker Pro software)
WOL: S1, S2, S3
ON/OFF switch to turn the docking station on and off
LED indication
Support for Kensington lock
USB-C 3.1 cable (100 cm)
OS: Windows 10/11, macOS, Android, Chrome OS and Linux with latest updates
Product Dimensions: 214 x 8 4 x 26 mm
Product weight: 400 g
Package dimensions: 226 x 132 x 72 mm
Package weight: 1760 g
SYSTEM REQUIREMENTS
Hardware Requirements:
Device with a free USB-C, USB4 or Thunderbolt 3/4 port
Power Delivery Requirements:
Device with a free USB-C, USB4 or Thunderbolt 3/4 port with Power Delivery support
Video Output Requirements:
Device with a free USB-C or USB4 port with DisplayPort Alternate Mode support or a Thunderbolt 3/4 port
Operating System:
Windows 10 / 11, macOS*, iPadOS**, Android**, Chrome OS and Linux with latest updates
