Description

Product Details

Brand: Raleigh

Specifications

Electric: Yes

Fork Type: Raleigh Steel Trekking Fork For E Bike

Frame Material: Alloy Frame AL6061

Frame Shape: Low step

Headset: Threaded 1" 1/8th Black

Total Bike Weight: 20kg

Battery: TranzX 250wh 36V 6.8Ah Battery

Battery Charging Time: 4 hours

Battery Integration: External

Battery Watts per Hour: 250Wh

Display: TranzX DP15 PST Display, 3 Assist Levels With Walk Function

Max Range: 30 miles

Motor: New TranzX F15 36v 250w Brushless Quick Stop Motor

Motor Position: Rear

Grips: Velo Comfort Grips

Handlebar: Raleigh 560mm Straight Bar Black

Saddle: Raleigh Ebike Saddle

Seatpost: Alloy Micro Adjust 33.9 X 460mm

Seatpost Clamp: 40.8 Clamp

Stem: Folding Alloy Stem

Front Brake: Alloy V-Brake

Number of Gears: 7

Rear Brake: Alloy V-Brake

Bottom Bracket: 124.5mm Square Taper

Cassette: 7 speed 14-34T freewheel

Chain: KMC 1/2" x 3/32" 6/7/8 Speed

Crankset: 48th Alloy Black With Alloy Chain-guide

Drivetrain: Chain

Front Shifter: Shimano Revoshift 7 Speed

Gear Shift: Derailleur Gear

Pedals: Folding Pedals With Anti Slip

Rear Derailleur: Altus 7/8 Speed

Front Wheel Hub: Alloy 36 Hole Black

Inner Tubes: 20 X 1.95 Presta

Rear Wheel Hub: TranzX R15 Motor

Rim: Double Wall Rim 36 Hole 20"

Tyres: Kenda K841 20 x 1.95 Reflective Side Wall

Wheel Set: Double Wall Rim 36 Hole 20" On R15 Motor HubDouble Wall Rim 36 Hole 20" On Alloy Hub

Front Light: Front Light Powered By TranzX System

Mudguards: Matt Black Thermoplastic

Rear Carrier: Integrated Alloy Carrier

Rear Light: Rear Light Powered By TranzX System

Weight Limits (Rider and Cargo): 110 KG
